Welcome to Myrmex Hive

Myrmex Hive is a decentralized, secure, and geeky agent orchestration framework built on top of the Model Context Protocol (MCP). It is designed to securely monitor, query, and manage distributed edge servers, Docker hosts, and Kubernetes nodes without exposing any ingress ports on your target systems.

1. Architecture & Security Model

Myrmex Hive is built for zero-trust environments where target edge systems (agents) must remain completely isolated from direct inbound network traffic.

flowchart TD
    %% Node Definitions
    subgraph Edge ["Target Edge Node (Myrmex Agent)"]
        Agent["Myrmex Agent<br/>(CPU/Mem/Disk, strict allowlist)"]
    end

    subgraph Gateway ["Central Hive Gateway"]
        SSHD["Secure SSHD Receiver<br/>(Port 2222)"]
        Orch["Myrmex Hive Orchestrator"]
        LLM["Ollama LLM<br/>(Gemma 4/2)"]
    end

    Client["Client / CLI / Portal<br/>(Stdio / SSE MCP Interface)"]

    %% Connections
    Agent -- "SSH Outbound Tunnel" --> SSHD
    SSHD -- "JSON-RPC over SSH channel" --> Orch
    Orch <--> LLM
    Client <--> Orch

    %% Styling / Colors
    classDef edgeNode fill:#282828,stroke:#fabd2f,stroke-width:2px,color:#ebdbb2;
    classDef gatewayNode fill:#282828,stroke:#fe8019,stroke-width:2px,color:#ebdbb2;
    classDef clientNode fill:#282828,stroke:#b8bb26,stroke-width:2px,color:#ebdbb2;

    class Agent edgeNode;
    class SSHD,Orch,LLM gatewayNode;
    class Client clientNode;

Security Principles (Why We Made These Choices)

2. Multi-Platform Installation Guide

Myrmex Hive supports Go, Nix, Linux, macOS, and Windows environments.

Nix / NixOS (Declarative Flake)

Add Myrmex Hive to your flake.nix inputs:

inputs.myrmex-hive.url = "github:olafkfreund/myrmex-hive";

You can then run the CLI tool directly:

nix run github:olafkfreund/myrmex-hive#myrmex -- --help

To deploy a Myrmex Agent or Gateway as a declarative systemd service on NixOS, enable the module in your configuration.nix:

{ inputs, config, pkgs, ... }: {
  imports = [ inputs.myrmex-hive.nixosModules.default ];

  services.myrmex-hive = {
    enable = true;
    role = "agent"; # Or "gateway"
    configPath = "/etc/myrmex/agent_config.json";
  };
}

Linux & macOS (Direct Install)

To download, compile, and configure the Agent as a background daemon (systemd on Linux, LaunchDaemon on macOS):

sudo ./install.sh

The installer automatically compiles the agent binary, generates secure Ed25519 keys, writes the config.json, and boots the service.

Windows (PowerShell Script)

To install the Agent on Windows Server or Windows 10/11, launch PowerShell as Administrator and run:

Set-ExecutionPolicy Bypass -Scope Process -Force
.\install.ps1

The PowerShell script compiles the binary, registers the agent configuration under C:\ProgramData\mcp-agent\, generates OpenSSH keys, and schedules a background task to launch the agent at system startup.

3. Configuration Setup

Agent Configuration (agent_config.json)

Allows you to define a single gateway or a list of multiple gateway addresses for High Availability (HA) failover cycling:

{
  "agent_id": "agent-nginx",
  "gateway_addr": "gateway-1.internal:2222",
  "gateway_addrs": [
    "gateway-1.internal:2222",
    "gateway-2.internal:2222"
  ],
  "private_key_path": "/etc/mcp-agent/id_ed25519",
  "allowed_commands": [
    {
      "name": "uptime",
      "args_regex": "^$"
    },
    {
      "name": "systemctl",
      "args_regex": "^(status|restart) (nginx|postgresql)$"
    }
  ]
}

Gateway Configuration (gateway_config.json)

Configures the receiver, TLS certs, OIDC/Tokens RBAC role mapping (admin, operator, read-only), and signed audit log path:

{
  "listen_addr": ":2222",
  "http_addr": ":8080",
  "host_key_path": "",
  "authorized_keys_path": "authorized_keys",
  "ollama_url": "http://localhost:11434",
  "ollama_model": "gemma4:e4b",
  "auth_token": "fallback_admin_token",
  "tokens": {
    "admin-token-123": "admin",
    "operator-token-456": "operator",
    "read-token-789": "read-only"
  },
  "audit_log_path": "audit.log"
}

Note: If audit_log_path is set, Myrmex Gateway records all /api/call and /api/chat executions alongside a cryptographic signature generated using the Gateway’s private SSH host key.

4. Local LLM Setup (Ollama & Gemma 4)

Myrmex Hive orchestrates actions and interprets output using local LLMs.

An optional Docker setup is available via profiles in docker-compose.test.yml preloaded with the gemma4:e4b model (offline-ready):

Option B: Manual Host Setup

  1. Install Ollama on your Gateway server.
  2. Pull the desired model (Gemma 4):
    ollama pull gemma4:e4b
  3. Ensure Ollama is running and accessible (default http://localhost:11434). Link it in gateway_config.json.

5. Using the Myrmex CLI (myrmex)

The Go-based Myrmex CLI allows operators to interact with the gateway, view agents, invoke tools, and launch the assistant directly from the terminal.

Global Options

CLI Command Reference

6. Real-Life Orchestration Scenarios

Scenario A: Automated Cluster Recovery

An operator issues a query: myrmex ask "Check load average on agent-db. If it's over 4.0, run diagnostic logs and let me know what process is consuming CPU."

  1. The orchestrator calls agent-db__get_metrics.
  2. The orchestrator parses the returned metrics JSON.
  3. If the load is over 4.0, the local Gemma model identifies that agent-db__run_command with argument {"cmd":"top"} (or an allowed diagnostics script) is available in the allowlist.
  4. The orchestrator executes the tool, parses the logs, and presents a clean, formatted report directly to the terminal.

Scenario B: Integration with Antigravity SDK

You can easily drive Myrmex Hive programmatically from other automated AI systems, such as Antigravity SDK agents. The gateway exposes standard endpoints (/api/chat and /api/call) protected by the secure bearer token. Your Antigravity agents can query the endpoint, receive structured tool list payloads, and trigger actions over the SSH tunnel.

Scenario C: Airgapped Gemma 4 Setup & Cryptographic Auditing

An enterprise administrator configures a secure, fully compliance-audited local assistant using the offline-ready Ollama side-service:

  1. Launch Ollama: The administrator starts the preloaded CPU-only Gemma 4 side-service in Docker:
    docker compose --profile ollama-cpu up -d
  2. Configure Gateway: In gateway_config.json, the gateway is linked to the Ollama endpoint:
    "ollama_url": "http://myrmex-ollama-cpu:11434",
"ollama_model": "gemma4:e4b"
  3. Execute Operator Request: An operator executes a compliance-audited CLI query:
    myrmex ask "Verify the nginx server is running on agent-nginx" --token "operator-token-456"
  4. Log & Verify Audit Event: Since the request has write-like evaluation steps, the gateway logs a cryptographically signed entry in audit.log showing the timestamp, token role (operator), API route (/api/chat), and base64 signature. The security auditor verifies the log authenticity using the gateway’s public SSH host key.

7. GCP Best Practices

For cloud deployments on Google Cloud Platform:

  1. VM Isolation: Deploy the Myrmex Gateway on a secure Compute Engine VM inside a private VPC. Expose the Gateway’s control interface (:8080) only through Identity-Aware Proxy (IAP) to enforce IAM roles.
  2. Kubernetes Agents: Deploy Myrmex Agents on Google Kubernetes Engine (GKE) as a DaemonSet to automatically monitor and manage GKE node resources.
  3. Secret Security: Avoid storing the Gateway auth token in config files. Fetch the token dynamically at startup from Google Secret Manager.

8. Airgapped Datacenters

In highly secure, airgapped systems:
